Treatment Principle
Adopting the Q-Switched ND: YAG model, the equipment uses laser to emit high energy instantaneously which smashing the pigment of pathological tissues, namely the laser leading explosive effect: High energy emits instantaneously, making particular wavelength laser penetrating epidermis and getting into pathological pigment tissues in only 6nms.
Then pigments expand in top speed and explode. The superficial epidermis would be bounded out of body, other part of the pigments would split into granules which would be engulfed by mcrophages, then exclude by the lymphatic system finally. The pigment becomes shallow gradually finally disappear while the surrounding normal skin tissues keep sound as they do not absorb particular wavelength laser.
Applications:
1. Remove all kinds of tattoos,birthmarks,moles,etc.
2. Removing the pigmentary skin pathological changes, pigmentation caused by color pigment mixture, corium spots, freckles, moles, birthmark, nevus of Ota, etc.
3. Effectively removing all kinds of embroidered eyebrow, soak lip, eyebrow/ eye/ lip line.
4. For skin rejuvenation,skin lift ,skin whitening, shrink pores and blackheads removal,etc.
Main Technical Advantages:
1. Advanced infrared aiming beam function, more easy and accurate operation for user
2. Newest Chromatic Touch screen operation system for different treatment items, Streamlined appearance, compact and portable design,very convenient for carrying and transporting.
3. The most newest laser handle with alloy steel material q-switch laser probes,532nm ,1064nm and 1320nm.
4. User can either press the handle button or step on the pedal to shot. Very convenient and humanized.
5. Imported Ruby Q switch laser and Italy Imported Special xenon lamp of pulse laser with longer life time.
6. Excellent water+air cooling system for long time continuously working under the high frequency.
7. The unique and intelligent flow detection system and fault self-checking system. High and new laser technology-instantaneous explosion with red laser aiming beam.
8. No damage for hair follicle, and no harm for ordinary skin.
Technical Parameter:
| Type | Ruby Q-switched Nd: Yag Laser |
| Wavelength | 1064nm & 532nm & 1320nm (black doll) |
| Energy | 1,000mj (can be customized to 1,500mj) |
| Frequency | 1–6Hz continuously adjustable (can be customized to 10Hz) |
| Pulse Width | 10ns |
| Lamp life | More than 10000000 shots |
| Operating Language | 6 kinds (can be customized) |
| Cooling System | Air Cooling+Water Cooling |
| Output Power | 1500W |
| Input Power | AC110/220±10% 50HZ/60HZ |
| Weight | 15kg |
| Package Dimensions | 530mm*460mm*350mm |
